| The Feuling Billet Dipsticks are made In America and they vent excessive crankcase pressure from the oil tank on Harley Touring Models through a PCV style breather. Blow-by is pressure that is forced past the rings and cylinder walls and ends up in the crankcase and then into the oil tank. All internal combustion engines have a certain amount of crankcase pressure and it does increase with miles. Large cubic inch engines have a tendency to have more blow by as well. The Vented Dipstick is easy to install, but I still suggest reading the sheet of instructions that come with it before starting installing this product.  Fittings and Set Screw  Porous Fitting Installed For Photo There are two ways that this system can work. One is with an internal porous filter element. Though this element gives a clean look it can produce an oil misting residue on the top of the dipstick. The other option is with a quick disconnect fitting and line with a filter element on the end of it. This is the recommended method. TOOLS NEEDED  .050 Allen Wrench 7/16 Box -Open End Wrench  Diagonal Cutters ASSEMBLY  Stock Oil Filler Dipstick Remove the stock dipstick and make sure the oil tank is full. If not add oil.  Feuling Dipstick Breather Kit
The breather consists of a perforated disc, replaceable filter element and umbrella flapper valve.  Tightening Hex ScrewThe cap is screwed on to the dipstick using a little 545 Loctite, which comes with the kit, this will help prevent leaking. Loctite is also added to the small 0.050 hex Allen screw in the side of the cover to lock the cap so it does not unscrew when the dipstick is removed.  Quick Disconnect Fitting Installed The quick disconnect fitting was installed using thread sealer. The assembly screws into factory fill spout just like a stock part. Lubricate the O-ring on the Feuling dipstick with O-ring lube or engine oil.  The filter was left in this position for photo. It was then tied up to be above the frame rail The line is run inside the frame rail, up under the seat then back down with the element resting between the engine and transmission mating area neatly out of the way. The line is secured in a couple of spots to hold it in place making sure the plastic wire ties did Not Pinch the Breather Line The line will need to be disconnected to remove the dipstick to check or ad oil but it does like the name implies disconnects quickly. CAUTION WHEN CHECKING OIL LEVEL THE DIPSTICK WILL BE HOT IF ENGINE HAS BEEN RUN For more information on this and other fine Feuling products go to www.FeulingParts.com |
